Model NO.
LP10-NEMA-G
Minimum order quantity
10 pieces
Supply Ability
10000 pieces / Month
Country of Origin
Shanghai , China
Quantity:

LP10-NEMA-G controller offers powerful functions, easy implementation, wiring free, reliable operation and easy-maintenance.

With all these advantages, LP10-NEMA-G controller is a high performance and energy saving product, specialized for intelligent street lighting.

　

Item

Parameter value

Remarks

1

Relay Parameter

250V/16A

2

Supply voltage

AC85-265V

3

Dimensions

84Dia.×97.8（mm）

　

4

IP Grade

IP65

　

5

Output rated current

4A

　

6

Dimming type

0-10V/PWM

Optional

7

Product output

Single-phase communication

　

8

Data collection

U,I,P.Q.COSΦ

　

9

Transmit power

20dBm±1dBm（max）

10

Sensitivity

-136dBm±1dBm（@SF=12）

11

Antenna gain

3DB

　

12

Antenna standing wave

《2.0

　

13

Antenna type

Built-in

　




  • Model Number：LP10-NEMA-G
  • Brand Name：LIPU
  • Place of Origin：China
